V.35 Over IP

• Administrative policies for adding, removing, disabling and renaming authorized users; limiting user access to assigned commands; and enabling only desired port numbers.

• User authentication directly or in conjunction with TACACS+ or RADIUS servers including RSA SecureID support for two factor trusted compliance.

• An SSH command interface encrypting management traffic with powerful 256 bit symmetric keys and NIST based passwords.

• Support of the SNMPv3 protocol for secure connectivity to SNMP element managers.

• In addition, administrative accounting data can be reported to syslog servers with accurate timestamps provided by an NTP source.

In Always-On mode, the Protector sends two identical packet streams simultaneously on the LAN1 and LAN2 ports of the local IP•Tube. The remote unit monitors both LAN1 and LAN2 incoming traffic and on a packet by packet basis selects the best packet to use for conversion from IP back to T1. In most cases, switching of the receive packet source between LAN1 and LAN2 can be done without T1 circuit interruption.

In “On-Demand” mode, the Protector only sends the duplicate packet stream over the second IP connection (LAN2 of the IP-Tube) if a failure is detected on the first IP connection. “On-Demand” connections can be used for cost savings or bandwidth reasons. For example, the expense associated with a backup IP Satellite connection for a full T1 (non-optimized T1 over IP requires 1.8 megabits per second) would dictate transmitting duplicate packets only during a failure condition.
