Transparent
E1 interface for E1 over IP Voice and Data
The
IP•Tube E1 encapsulates full and fractional E1 and TDM
circuits, along with their framing and signaling bits, into
IP packets. The IP•Tube’s E1 Over IP, E1 Over Ethernet
connection provides for the transparent interconnection of PBXs,
Telecom Switches and E1 based communication systems via LANs,
WANs, MANs, and Wireless Ethernet.
|
| IP•Tube
E1 Features |
|
Transparent
Interconnect
IP•Tube
E1 transparent operation maintains the proprietary signaling
required to support PBX features such as call conferencing,
call forwarding, caller ID and SS7. Legacy phone equipment investment
is preserved. Transparent support for Modem, Fax, or Data circuits.
The IP•Tube E1 has a E1 interface that connects directly
to the E1/DS1 interface of Phone Systems or E1 Data Communication
Equipment.
|
- Lossless
Data Compression Option
- The
IP•Tube E1C detects idle/redundant data within each DS0
resulting in as much as 56 to 1 bandwidth savings. E1 over IP
bandwidth is not consumed by silent or redundant circuits. Management
of the IP•Tube E1 is accomplished with a Command Line
Interface that is accessed through a Console or Telnet connection.
Common templates provide for cut and Paste configuration.
|
 |
Service
Quality Packet Prioritizing
The IP•Tube E1 uses the Type of Service byte in the IP packets
to prioritize the encapsulated E1 frames. The setting of the TOS
byte can be used to ensure that the real time TDM data from the
IP•Tube E1 is ensured high priority. |
Pay-As-You-Grow
Compression Upgrade
At any time, the E1 port on the IP•Tube E1 can be upgraded
to Lossless Data Compression with a simple software-based license
key installation. If upon installation, you determine that your
IP•Tube E1 is best deployed with Lossless Data Compression,
you're still in business with the port field compression upgrade! |
Rack
Mount Kit
The IP-Tube family is ready for your most demanding central office
or data center environments. With the Rack Mount Kit, IP•Tube
products are easily installed in 19" and 23" racks. Easy
access to both front and rear sides facilitates technician maintenance
procedures. |
